Huawei – SFP-10G-ZR 10GBASE-ZR SFP+ Transceiver Module

Description

Huawei – SFP-10G-ZR 10GBASE-ZR SFP+ Transceiver Module

DETAILS:

Huawei – SFP-10G-ZR 10GBASE-ZR SFP+ Transceiver Module

SPECIFICATION:

The SFP-10G-ZR is a high-performance, 10GBASE-ZR Small Form-factor Pluggable (SFP+) transceiver module specifically designed for 10 Gbit/s data transmission over single-mode fiber (SMF) networks. This hot-swappable module ensures reliable, long-distance connectivity in various applications, including:

• Data centers
• Enterprise networks
• Metropolitan area networks (MANs)
• High-performance computing (HPC) clusters
• Storage area networks (SANs)
• Cloud computing infrastructure

Key Features

• Supports 10 Gbit/s transmission rate
• Single-mode fiber (SMF) supports up to 80 km
• Digital Diagnostic Monitoring (DDM) supported for real-time monitoring
• Operating temperature: 0°C to 70°C (32°F to 158°F)
• Compliant with 10GBASE-ZR standard
• Low power consumption

Optical Characteristics

Transmitter

• Center wavelength: 1550 nm
• Maximum Tx optical power: 4.0 dBm
• Minimum Tx optical power: 0 dBm
• Minimum extinction ratio: 9 d

Receiver

• Rx sensitivity: -24.0 dBm
• Overload power: -7.0 dBm

Interface and Connectivity

• Connector type: LC
• Optical fiber type: Single-mode fiber (SMF)

Applications

• Data centers
• Enterprise networks
• Metropolitan area networks
• High-speed computing
• Storage area networks

Benefits

• High-speed, long-distance connectivity
• Reliable, error-free data transmission
• Easy installation and maintenance
• Compatible with industry-standard SFP+ slots
• Cost-effective solution for 10 Gbit/s networks

Compliance

• IEEE 802.3ae 10GBASE-ZR standard
• SFP+ MSA (Multi-Source Agreement) compliant

Ordering Information

• Part Number: 02310SNN
• Model: SFP-10G-ZR
