ITC – T-4120UC/ T-4240UC 2/4 Channel Matrix Digital Mixer Amplifier

Brand Name:  ITC
Part Number: T-4120UC/ T-4240UC
Product Type:  ITC – T-4120UC/ T-4240UC 2/4 Channel Matrix Digital Mixer Amplifier
Specification: Please refer to the Datasheet on the Manufacturer’s Datasheet
Warranty: Manufacturer Standard Warranty

This product is currently out of stock and unavailable.

  Enquire Now
Compare

Description

ITC – T-4120UC/ T-4240UC 2/4 Channel Matrix Digital Mixer Amplifier

DETAILS:

ITC – T-4120UC/ T-4240UC 2/4 Channel Matrix Digital Mixer Amplifier

Description:

Provide regional for power amplification PA system, it is suitable for clubs, venues, shopping malls and other places with PA system that require multi-channel high-power digital power amplifiers.

Features:

  • 120W/240W constant impedance and voltage high performance digital power amplifier (4-16Ω/100V) with 2/4 channel outputs.
  • Built-in MP3 recording function.
  • 6-channel independent volume control.
  • 6-channel audio sources can be input to each channel output through matrix configuration.
  • INPUT 1-4 with adjustable gain.
  • 2/4-channel outputs support independent power amplifier tone adjustment.
  • Support 4 remote microphone inputs.
  • Built-in MP3 (U disk/SD card) player function.
  • Built-in FM radio function.
  • Adopt 2.4-inch high-grade TFT display.
  • 2/4-channel outputs support the remote panel control.
  • Distortion, protection, signal, output status indicator.
  • INPUT 1-4 channels support phantom power.
  • 1-4 Channels enjoy priority and mixing selection function.
  • Enjoy priority input port of EMC alarm sound source.
  • ALARM port to play the specified alarm track.
  • Built-in Bluetooth function and external high-gain Bluetooth antenna to connect to mobile phones / computers.
  • 2/4-channel MUTE ports can be connected to the fire control port.
  • Priority: EMC>MUTE>REMOTE MIC>INPUT 1-4>LINE 1-2.

Specifications:

Model T-2120UC T-2240UC T-4120UC T-4240UC
Output terminal 4-16Ω, 100V
Output power 2*120W 2*240W 4*120W 4*240W
Input sensitivity & impedance INPUT1-4: 5mV-350MV±40MV/600Ω;

LINE1-2: 350mV±40MV/10KΩ unbalanced RCA connector;

EMC: 775mV/10KΩ unbalanced European connector

Output sensitivity & source impedance CH1-2: 1000mV/470Ω unbalanced RCA connector
Tone Bass: ±10dB at 100Hz

Treble: ±10dB at 10KHz

Frequency response 80~16KHz(+1dB,-3dB)
SNR INPUT1-4:66dB; LINE1-2:80dB
THD < 0.5% (at 1KHz, 1/3 rated power)
Phantom power 48V (±2V)
Protection High temperature, overload, short circuit
Cooling Fan forced cooling
Power consumption 370W 650W 650W 1200W
Power supply 230V/50Hz
Dimension 484x395x88mm
Weight 6.0kg 6.2kg 7.3kg 7.6kg



Additional information

Power (Mega Watt)

120 MW, 240 MW
