TS-0604 Series TS-0604M Digital Conference System Controller

ITC – TS-0604 Series TS-0604M Digital Conference System Controller

Brand Name: ITC
Part Number: TS-0604M
Product Type: ITC – TS-0604 Series TS-0604M Digital Conference System Controller
Specification: Please refer to the Datasheet on the Manufacturer’s Datasheet
Warranty: Manufacturer Standard Warranty
Add to wishlist
  Enquire Now
Compare
SKU: TS-0604M Categories: , , , Tags: , ,
ITC

Description

ITC – TS-0604 Series TS-0604M Digital Conference System Controller

Details:

ITC – TS-0604 Series TS-0604M Digital Conference System Controller

Description:

Advanced Conferencing Solutions for Efficient Meetings

The ITC TS-0604M is a cutting-edge digital conference system controller designed for seamless communication in various settings, including:

  • Boardrooms and meeting rooms
  • Video conferencing and webinars
  • Training sessions and seminars
  • Council chambers and town halls
  • Large conference venues and auditoriums

Key Features:

  • Modular design for easy expansion and customization
  • High-quality digital audio with echo cancellation and noise reduction
  • Plug-and-play connectivity for seamless setup
  • User-friendly interface with intuitive controls and LCD display
  • Compatible with various microphone options (gooseneck, tabletop, and handheld)
System Components:
  • Central Control Unit (CCU)
  • Chairman Unit
  • Delegate Units
  • Microphones (optional)

Advanced Features:

  • Automatic video switching and audio mixing
  • Support for up to 60 microphone units
  • Priority and mute functions for efficient meetings
  • Voice-activated or manual microphone control
  • Compatible with ITC audio-visual equipment and third-party devices
  • Firmware upgradeable for future functionality expansion

Specification:

Model TS-0604M
Input Power Supply ~90-132V/180-264V 50/60Hz  by switch
Mic Capacity ≤4096
Channel Number 1 CH
Frequency Response 30 ~ 20KHz
SNR >72dB(A)
Channel Crosstalk >80 dB
THD <0.05%
Audio Input LINE IN: 775mV  unbalanced
MIC IN : 50mV unbalanced
Audio Output LINE OUT : 1V  unbalanced
REC OUT: 200mV  unbalanced
Output Load >1K
Serial Port Connect to PC and video tracking controller
Static Power Consumption 10W
Output Consumption 340W
Connect Cable Special cables (8 cores)
Connector Reliability Reliability
Standard IEC60914
Operation Temp. -10℃~+60℃
Operation Humidity 20%~80% related humidity, no condensing
Color Black
Weight 3Kg
Dimension 484 ×305× 88mm
Installation Method 19 inch standard rack
