ITC – TS-9408UHM Seamless HD Matrix Network Switch
Details:
ITC – TS-9408UHM Seamless HD Matrix Network Switch
Features:
The TS-9408UHM is a high-performance, seamless HD matrix network switch designed for commercial and residential applications. It allows users to route and switch up to 8 HDMI sources to 8 HDMI displays, with support for 4K@60Hz resolution and HDR (High Dynamic Range). This switch features a built-in scaler, allowing for seamless switching between sources without any visible delay or artifacts.
- Input/Output:
- 8 HDMI inputs with auto-detection and priority switching
- 8 HDMI outputs with individual audio and video settingsSupports up to 4K@60Hz (3840×2160) resolution with chroma subsampling 4:4:4
- Compatible with HDR (High Dynamic Range) content, including HDR10, HLG, and Dolby Vision
- Seamless switching between sources with built-in scaler
- Supports seamless switching modes, including instant switching and fade-to-black
- Supports up to 7.1 channels of audio, including Dolby Atmos and DTS:X
- Individual audio settings for each output, including volume, mute, and audio delay
- Ethernet port for network control, updates, and remote access
- Compatible with Telnet, RS-232, and IR control for seamless integration with third-party control systems
- Supports HDMI 2.0 and HDCP 2.2 for maximum compatibility
- Built-in web interface for easy setup, configuration, and firmware updates
- Compatible with third-party control systems, including Crestron, AMX, and Control4
- Supports EDID management and learning for optimal source and display compatibility
- Dimensions: 17.3 inches (440mm) x 1.7 inches (43mm) x 5.5 inches (140mm)
- Weight: 4.4 pounds (2kg)
- Power: 12V DC, 2A power supply with built-in power protection and redundancy
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Humidity: Up to 80% RH (non-condensing)
Specifications
| Model | TS-9408UHM |
| Number of input cards | 2 |
| Number of output cards | 2 |
| Number of control cards | 1 |
| Input channel | 8 channel |
| Output channel | 8 channel |
| Serial port | 1×RS-232 (9-pin female D-type interface) |
| Baud rate and protocol | 9600; data bits: 8 bits, stop bits: 1, no parity bit |
| RS-485 control interface | 4-digit 3.8mm Phoenix interface, work with touch panel |
| Ethernet control interface | RJ-45 female interface |
| Ethernet control rate | Adaptive 10M/100M, full duplex or half duplex |
| Power supply | AC 100V~240V, 50/60Hz, international adaptive power supply |
| Ambient temperature | -20℃—+70℃ |
| Dimension (mm) | 484 (L) x 356 (W) x 132 (H) |
