Ramcro – Security & Sound (#22-4c BC CMR)

Details:

Ramcro – Security & Sound (#22-4c BC CMR)

Specifications:

The Ramcro cable is an alternative to the Belden cable

Security & Sound Cable, Riser-CMR, 4-22 AWG stranded bare copper conductors with polypropylene insulation, PVC jacket with ripcord

Technical Specifications

Product Overview

• Suitable Applications: Security System, Intercom/PA, Audio/Speaker, Power-Limited Controls

Construction Details

Conductor

• Element: Conductor(s)
• of Elements: 4
• Size: 22 AWG
• Stranding: 7×30
• Material: BC – Bare Copper

Insulation

• Element: Conductor(s)
• Material: PVC – PP – Polypropylene
• Thickness: 0.017 in (0.20 mm)
• Diameter: 0.045 in (1.1 mm)
• Color Code: Black, Red, White, Green

Outer Jacket

• Material: PVC – Polyvinyl Chloride
• Thickness: 0.017 in (0.43 mm)
• Diameter: 0.141 in (3.58 mm)
• Ripcord: Yes
• Overall Cable Diameter (Nominal): 0.141 in (3.58 mm)

Electrical Characteristics:

Electricals

• Element: Conductor(s)
• Conductor DCR: 16.9 Ohm/1000ft
• Capacitance Cond-to-Cond: 17 pF/ft (56 pF/m)
• Current: 4.8 Amps per Conductor at 25ºC

Voltage

• UL Voltage Rating: 300 V

Mechanical Characteristics:

Temperature

• UL Temperature: 75°C
• Operating: -20°C to +75°C

Bend Radius

• Stationary Min.: 1.4 in (36 mm)
• Installation Min.: 1.4 in (36 mm)
• Pull Tension: 36 lbs (16 kg)
• Bulk Cable Weight: 13 lbs/1000ft

Standards and Compliance:

• Environmental Suitability: Indoor – Riser, Indoor
• Flammability / Reaction to Fire: UL 1666 Riser, FT4, IEC 60332-1-2
• CPR Compliance: CPR Euroclass: Eca
• NEC / UL Compliance: Article 800, CMR
• CEC / C(UL) Compliance: CMG
• European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
• UK Regulation Compliance: UKCA Mark
• APAC Compliance: China RoHS II (GB/T 26572-2011)
• Plenum Number: 6502UE
