Toshiba – Hard Disk S300 6Tb 5400Rpm 256Mb Upto 64 Camera, Hdkpb06Z0A01, CHDE6TTOSS300256MB

Description

Toshiba – Hard Disk Surveillance S300 6Tb

DETAILS:

Toshiba – Hard Disk Surveillance S300 6Tb

With surveillance systems, nothing but the best is good enough. The Toshiba 3.5-inch S300 is built to meet the highest demands. With support for up to 64 high-resolution surveillance video cameras simultaneiously and up to 2 TB capacity, it brings everything into clear view. Each S300 is built with the highest-quality components and has passed rigorous tests to ensure 24×7 reliability and performance. That?s Toshiba quality you can trust under the harshest working conditions.

SPECIFICATION:

Basic Specifications

• Form factor: 3.5-inch
• Interface: 6.0 Gbit/s
• Number of cameras supported:? ?32
• Drive bays supported:?? up to 8
• Shock Sensor: Yes
• Advanced Format (AF): Yes
• RoHS compatible: Yes
• Halogen free: Yes
• Recording Technology:? SMR

Performance

• Rotational speed (rpm): 5400
• Max. data transfer speed (sustained MB/s Typ.): 184
• Buffer size (MB):? 128
• Average latency (ms):??? 5.56

Reliability

• Workloads (TB/year):? 180
• MTTF (hours):?? 1,000000
• Unrecoverable error rate: 1 per 10^14
• 24 x 7 operation: Yes
• Load/Unload cycle: 600 000

Power Management

• Supply voltage : 5 V DC ?5%, 12 V DC ?10%
• Consumption (operating): 4.01 W typ.
• Consumption (active idle): 2.08 W typ.

Environmental

• Temperature (operating/non-operating) 😕 0 to 70?C, -40 to 70 ?C
• Vibration (operating):? ?4.90 m/s2 {0.50 G}(5 to 350 Hz)2.45 m/s2 {0.25 G} (350 to 500 Hz)
• Vibration (non-operating):? 29.4 m/s2 {3.0 G} (5 to 500 Hz)
• Shock (operating): 686 m/s2 {70 G} (2 ms duration)
• Shock (non-operating): 3430 m/s2 {350 G} (2 ms duration)
• Acoustics (idle mode): 21 dB typ.

Physical

• Dimensions:? 147 (L) x 101.85 (W) x 26.1 (H)
• Weight: 440 g
