TP-LINK – AC1200 Wi-Fi Bluetooth 4.2 PCIe Adapter

Description

TP-LINK – AC1200 Wi-Fi Bluetooth 4.2 PCIe Adapter

DETAILS:

TP-LINK – AC1200 Wi-Fi Bluetooth 4.2 PCIe Adapter

• Super-Fast Speed: Make full use of your network with AC1200 WiFi speeds (867 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band).1
• Bluetooth 4.2: Achieve 2.5? faster speed and 10? more packet capacity than Bluetooth 4.0. 3
• Broad Wireless Range: Connect to your WiFi from further away with two external high-gain antennas ensuring greater range and enhanced stability.
• Easy Installation: Plug the adapter into an available PCI-E slot and install the drivers with the included CD.

HARDWARE FEATURES

• Interface: PCI Express
• Dimensions: 4.8 ? 3.3 ? 0.85 in (120.8 ? 83.2 ? 21.5 mm)
• Antenna: 2 Detachable External Antennas

BLUETOOTH FEATURES

• Standards and Protocols: Bluetooth 4.2, Bluetooth 4.0
• Interface: USB 2.0

WIRELESS FEATURES

• Wireless Standards: IEEE 802.11b/g/n 2.4 GHz, IEEE 802.11a/n/ac 5 GHz
• Signal Rate:

1. 11ac: Up to 867 Mbps(dynamic)
2. 11n: Up to 300 Mbps(dynamic)
3. 11a: Up to 54 Mbps(dynamic)
4. 2.4 GHz:

• Reception Sensitivity:

1. 5 GHz:
2. 11ac HT80: -59.0dBm
3. 11n HT40: -68.5dBm
4. 11a 54Mbps: -73.5dBm
5. 11a 6Mbps: -91dBm

• Transmit Power :

1. 5 GHz: 21.5dBm(FCC)
2. 2.4 GHz : 20.5dBm(FCC)

• Wireless Modes: Infrastructure mode
• Wireless Security: WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
• Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM

OTHERS

• Certification: FCC, RoHS
• Package Contents:

1. AC1200 WiFi Bluetooth 4.2 PCIe Adapter Archer T5E
2. Low-Profile and Full Height Brackets
3. Quick Installation Guide
4. Bluetooth USB Cable
5. Resource CD

• System Requirements: Windows 11/10/8.1/8/7 (32/64 bit)
• Environment:

1. Operating Temperature: 0?~40? (32? ~104?)
2. Storage Temperature: -40?~70? (-40? ~158?)
3. Operating Humidity: 10%~90% non-condensing
4. Storage Humidity: 5%~90% non-condensing.
